性能Performance

负载能力Maximum load capacity

kg

1500

2000

载荷中心距Load center

Q

mm

500

500

起升高度Maximum lifting height

H3

mm

见门架参数

见门架参数

前移距离Forward distance

E

mm

570

570

无负载行驶速度Driving speed (unload)

km/h

5.2

5.2

负载行驶速度Driving speed (load)

km/h

5.2

5.2

无负载起升速度Lifting speed (unload)

mm/s

115

115

负载起升速度Lifting speed (load)

mm/s

92

92

无负载下降速度Lowering speed (unload)

mm/s

173

173

负载下降速度Lowering speed (load)

mm/s

530

530

无负载最大爬坡能力Max climbing ability (unload )

%

8

8

负载最大爬坡能力Max climbing ability (load )

%

5

5

整车重量 Weight (with battery)

kg

≈2100

≈2300

尺寸Dimensions

整车长度（门架没前移不含货叉）Overall length ( no reach,without fork)

L

mm

1890

1890

整车长度（门架没前移含货叉）Overall length ( no reach,with fork)

G

mm

2420

2420

门架前移后整车长度Overall length (mast reach,with fork)

G1

2950

2950

整车宽度Overall width

B

mm

1034

1034

门架闭合高度Height of mast closed

H1

mm

见门架参数

见门架参数

起升时门架最大高度Height of mast open(incl Load-Backrest)

H4

mm

见门架参数

见门架参数

轴距Wheelbase

Y

mm

1510

1510

货叉长度Fork length

mm

1070

1070

货叉面宽度Fork width

mm

100

100

货叉降至最低高度Fork lowered height

S

mm

50

50

货叉外侧宽度可调范围Fork spread width

R

mm

210-700

210-700

最小离地间隙Minimum ground clearance

mm

55

55

最小转弯半径理论值（合起踏板）Turning radius (Close the pedal )

Wa

mm

1771

1771

最小转弯半径理论值（展开踏板）Turning radius( open the pedal)

Wa1

mm

2193

2193

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

Asts

mm

2640

2640
