性能Performance

负载能力Maximum load capacity

kg

1500

2000

2500

载荷中心距Load center

Q

mm

500

500

500

起升高度Maximum lifting height

H3

mm

见门架参数

见门架参数

见门架参数

前移距离Forward distance

E

mm

550

550

550

货叉倾斜范围Tilt of fork（forward/backward）

°

3/5

3/5

3/5

无负载行驶速度Driving speed (unload)

km/h

8

8

8

负载行驶速度Driving speed (load)

km/h

7

7

7

无负载起升速度Lifting speed (unload)

mm/s

224

224

224

负载起升速度Lifting speed (load)

mm/s

94

94

94

无负载下降速度Lowering speed (unload)

mm/s

224

224

224

负载下降速度Lowering speed (load)

mm/s

700

700

700

无负载最大爬坡能力Max climbing ability (unload )

%

15

15

15

负载最大爬坡能力Max climbing ability (load )

%

8

8

8

整车重量 Weight (with battery)

kg

≈2500

≈3000

≈3100

尺寸Dimensions

整车长度（门架没前移不含货叉）Overall length ( no reach,without fork)

L

mm

1890

1890

1990

整车长度（门架没前移含货叉）Overall length ( no reach,with fork)

L1

mm

2479

2479

2579

门架前移后整车长度Overall length (mast reach,with fork)

L2

mm

3029

3029

3129

整车宽度Overall width

B

mm

1270

1270

1270

护顶架高度Overhead guard height

mm

2190

2190

2190

门架闭合高度Height of mast closed

H1

mm

见门架参数

见门架参数

见门架参数

起升时门架最大高度Height of mast open(incl Load-Backrest)

H4

mm

见门架参数

见门架参数

见门架参数

轴距Wheelbase

Y

mm

1510

1510

1610

货叉长度Fork length

mm

1070

1070

1070

货叉面宽度Fork width

mm

100

100

100

货叉降至最低高度Fork lowered height

S

mm

50

50

50

货叉外侧宽度可调范围Fork spread width

R

mm

210-820

210-820

210-820

最小离地间隙Minimum ground clearance

mm

30

30

30

最小转弯半径理论值Turning radius

Wa

mm

1783

1783

1882

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

Asts

mm

2673

2673

2772
