性能Performance

负载能力Maximum load capacity

kg

2000

载荷中心距Load center

Q

mm

600

起升高度Maximum lifting height

H3

mm

见门架参数

无负载行驶速度Driving speed (unload)

km/h

5.5

负载行驶速度Driving speed (load)

km/h

5

无负载起升速度Lifting speed (unload)

mm/s

180

负载起升速度Lifting speed (load)

mm/s

120

无负载下降速度Lowering speed (unload)

mm/s

140

负载下降速度Lowering speed (load)

mm/s

114

无负载最大爬坡能力Max climbing ability (unload )

%

7

负载最大爬坡能力Max climbing ability (load )

%

6

整车重量 Weight (with battery)

kg

≈1200

尺寸Dimensions

整车长度（合起踏板）Overall length (Close the pedal )

L

mm

2138

整车长度（展开踏板）Overall length ( open the pedal)

mm

2555

整车宽度Overall width

B

mm

1046

门架闭合高度Height of mast closed

H1

mm

见门架参数

起升时门架最大高度Height of mast open(incl Load-Backrest)

H4

mm

见门架参数

轴距Wheelbase

Y

mm

1508

货叉长度Fork length

mm

1150

货叉面宽度Fork width

mm

190

货叉降至最低高度Fork lowered height

S

mm

90

货叉外侧宽度Fork outside width

mm

680

最小离地间隙Minimum ground clearance

mm

20

最小转弯半径理论值（合起踏板）Turning radius (Close the pedal )

Wa

mm

1800

最小转弯半径理论值（展开踏板）Turning radius( open the pedal)

Wa1

mm

2175

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

Asts

mm

2470

二级门架
Duplex mast

2500

1734

2976

3000

1984

3476

3500

2234

3976

三级门架
Triplex mast

4000

1814

4496

4500

1984

4966

5000

2154

5476

5500

2314

5956

6000

2484

6436
