性能Performance

负载能力Maximum load capacity

kg

2000

载荷中心距Load center

Q

mm

500

起升高度Maximum lifting height

H3

mm

见门架参数

无负载行驶速度Driving speed (unload)

km/h

5.5

负载行驶速度Driving speed (load)

km/h

5

无负载起升速度Lifting speed (unload)

mm/s

121

负载起升速度Lifting speed (load)

mm/s

81

无负载下降速度Lowering speed (unload)

mm/s

105

负载下降速度Lowering speed (load)

mm/s

103

无负载最大爬坡能力Max climbing ability (unload )

%

7

负载最大爬坡能力Max climbing ability (load )

%

6

整车重量 Weight (with battery)

kg

≈1800

尺寸Dimensions

整车长度（合起踏板）Overall length (Close the pedal )

L

mm

3095

整车长度（展开踏板）Overall length ( open the pedal)

L1

mm

3500

整车宽度Overall width

B

mm

940

门架闭合高度Height of mast closed

H1

mm

见门架参数

起升时门架最大高度Height of mast open(incl Load-Backrest)

H4

mm

见门架参数

轴距Wheelbase

Y

mm

1630

货叉长度Fork length

mm

1070

货叉面宽度Fork width

mm

100

货叉降至最低高度Fork lowered height

S

mm

50

货叉外侧宽度可调范围Fork spread width

mm

210-670

最小离地间隙Minimum ground clearance

mm

55

最小转弯半径理论值（合起踏板）Turning radius (Close the pedal )

Wa1

mm

1828

最小转弯半径理论值（展开踏板）Turning radius( open the pedal)

Wa

mm

2317

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

Asts

mm

3306

一级门架
Single mast

1600

2095

2366

二级门架
Duplex mast

2000

1485

2766

2500

1735

3266

3000

1985

3766

3500

2235

4266

4000

2485

4766
