性能Performance

负载能力Maximum load capacity

kg

500

1000

1500

2000

2500

3000

载荷中心距Load center

mm

350

500

500

500

500

500

起升高度Maximum lifting height

mm

2000

3000

3000

3000

3000

3000

无负载行驶速度Driving speed (unload)

km/h

14

14

14

14

14

15

负载行驶速度Driving speed (load)

km/h

13

13

13

13

13

13

无负载起升速度Lifting speed (unload)

mm/s

220

190

190

190

190

300

负载起升速度Lifting speed (load)

mm/s

200

160

160

160

160

260

无负载最大爬坡能力Max climbing ability (unload )

%

12

12

12

12

12

15

负载最大爬坡能力Max climbing ability (load )

%

10

10

10

10

10

12

整车重量 Weight (with battery)

kg

≈820

≈1520

≈2180

≈2480

≈2850

≈4200

尺寸Dimensions

整车长度（含货叉）Overall length（with fork）

mm

2130

2870

3220

3290

3420

3790

整车长度（不含货叉）Overall length（without fork）

mm

1380

1800

2150

2220

2350

2570

整车宽度Overall width

mm

720

960

1120

1120

1180

1280

门架闭合高度Height of mast closed

mm

1600

2050

2090

2100

2100

2100

起升时门架最大高度Height of mast open(incl Load-Backrest)

mm

2700

3950

3950

3950

3950

4200

护顶架高度Overhead guard height

mm

1780

1900

2020

2050

2080

2150

座椅高度Seat height

mm

860

930

1080

1080

1150

1200

货叉倾斜范围Tilt of fork（forward/backward）

°

5/10

5/10

5/10

5/10

5/10

5/10

轴距Wheelbase

mm

890

1200

1450

1450

1560

1720

货叉长度Fork length

mm

750

1070

1070

1070

1070

1220

货叉面宽度Fork width

mm

80

100

100

100

100

120

货叉降至最低高度Fork lowered height

mm

40

40

40

40

40

50

货叉外侧宽度可调范围Fork spread width

mm

180-670

220-920

220-980

220-980

220-1060

350-1170

最小离地间隙Minimum ground clearance

mm

80

100

90

90

90

100

最小转弯半径理论值Turning radius

mm

1250

1680

1980

2150

2180

2200

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

mm

2800

3200

3600

3664

4600

4664
