性能Performance

负载能力Maximum load capacity

kg

2000

载荷中心距Load center

mm

600

起升高度Maximum lifting height

mm

205

无负载行驶速度Driving speed (unload)

km/h

4.5

负载行驶速度Driving speed (load)

km/h

3.8

无负载起升速度Lifting speed (unload)

mm/s

40

负载起升速度Lifting speed (load)

mm/s

25

无负载下降速度Lowering speed (unload)

mm/s

40

负载下降速度Lowering speed (load)

mm/s

50

无负载最大爬坡能力Max climbing ability (unload )

%

10

负载最大爬坡能力Max climbing ability (load )

%

6

整车重量 Weight (with battery)

kg

≈166

尺寸Dimensions

整车长度Overall length

mm

1765

整车宽度Overall width

mm

560/685

轴距Wheelbase

mm

1280

货叉长度Fork length

mm

1150/1200

货叉面宽度Fork width

mm

160

货叉降至最低高度Fork lowered height

mm

85

货叉外侧宽度Fork outside width

mm

560/685

最小离地间隙Minimum ground clearance

mm

30

最小转弯半径理论值Turning radius

mm

1420

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

mm

1835
