性能Performance

负载能力Maximum load capacity

kg

2000

2500

3000

载荷中心距Load center

mm

600

600

600

起升高度Maximum lifting height

mm

190

205

205

无负载行驶速度Driving speed (unload)

km/h

3

5.5

5.5

负载行驶速度Driving speed (load)

km/h

2.5

5

5

无负载起升速度Lifting speed (unload)

mm/s

45

25

25

负载起升速度Lifting speed (load)

mm/s

35

20

20

无负载下降速度Lowering speed (unload)

mm/s

40

25

25

负载下降速度Lowering speed (load)

mm/s

50

40

40

无负载最大爬坡能力Max climbing ability (unload )

%

7

7

7

负载最大爬坡能力Max climbing ability (load )

%

5

5

5

整车重量 Weight (with battery)

kg

≈330

≈360

≈370

尺寸Dimensions

整车长度Overall length

mm

1630

1780

1780

整车宽度Overall width

mm

680

680

680

轴距Wheelbase

mm

1265

1358

1358

货叉长度Fork length

mm

1150

1150

1150

货叉面宽度Fork width

mm

160

160

160

货叉降至最低高度Fork lowered height

mm

85

85

85

货叉外侧宽度Fork outside width

mm

680

680

680

最小离地间隙Minimum ground clearance

mm

5

5

5

最小转弯半径理论值Turning radius

mm

1440

1570

1570

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

mm

2115

2150

2150
