性能Performance

负载能力Maximum load capacity

kg

2000

2500

3000

载荷中心距Load center

mm

600

600

600

起升高度Maximum lifting height

mm

205

205

205

无负载行驶速度Driving speed (unload)

km/h

5.5

5.5

5.5

负载行驶速度Driving speed (load)

km/h

5

5

5

无负载起升速度Lifting speed (unload)

mm/s

50

50

50

负载起升速度Lifting speed (load)

mm/s

30

30

30

无负载下降速度Lowering speed (unload)

mm/s

57

57

57

负载下降速度Lowering speed (load)

mm/s

57

57

57

无负载最大爬坡能力Max climbing ability (unload )

%

7

7

7

负载最大爬坡能力Max climbing ability (load )

%

6

6

5

整车重量 Weight (with battery)

kg

≈680

≈690

≈700

尺寸Dimensions

整车长度（合起踏板）Overall length (Close the pedal )

mm

1775

1775

1775

整车长度（展开踏板）Overall length ( open the pedal)

mm

2280

2280

2280

整车宽度Overall width

mm

735

735

735

轴距Wheelbase

mm

1417

1417

1417

货叉长度Fork length

mm

1150

1150

1150

货叉面宽度Fork width

mm

170

170

170

货叉降至最低高度Fork lowered height

mm

85

85

85

货叉外侧宽度Fork outside width

mm

685

685

685

最小离地间隙Minimum ground clearance

mm

5

5

5

最小转弯半径理论值（合起踏板）Turning radius (Close the pedal )

mm

1625

1625

1625

最小转弯半径理论值（展开踏板）Turning radius( open the pedal)

mm

2135

2135

2135

直角堆垛通道宽度(托盘1000x1200)1200跨货叉方向Aisle width for pallet 1000*1200crossway

mm

2312

2312

2312
